CADEX MAX GXR WHEELS

Cadex

CADEX MAX GXR WHEELS

$2,399.99
WHEEL FRONT 12x100
Enquire Now

Engineered for high-speed gravel racing, the CADEX Max GXR WheelSystem combines aerodynamic efficiency, system stiffness, and impact resistance in a fully integrated design. A deep 50mm rim profile, wide internal widt...

Read full description ↓
About This Product

CADEX MAX GXR WHEELS

Engineered for high-speed gravel racing, the CADEX Max GXR WheelSystem combines aerodynamic efficiency, system stiffness, and impact resistance in a fully integrated design. A deep 50mm rim profile, wide internal width, and reinforced sidewalls deliver speed and control across rough terrain, while the integrated Max hub and carbon spoke system optimise power transfer under load.

CADEX MAX GXR WHEELS
CADEX MAX GXR WHEELS

CADEX MAX GXR WHEELS — Key Features

  • 50mm Aero Rim Profile – A deep 50mm rim profile minimises aerodynamic efficiency, reducing drag for sustained high-speed performance in race conditions.
  • Integrated Max Hub And Spoke Technology – A one-piece hub, flange, spoke, and rim structure forms a fully integrated system that minimises drag, smooths airflow, and maximises real-world efficiency at speed.
  • 25mm Inner Width – Optimised inner width supports higher gravel tyre volumes at lower pressures, increasing the contact patch for improved traction, compliance, and control.
  • Wide Guard Rim Protection – Reinforced 5mm sidewalls defend against rim strikes and pinch flats, eliminating the need for tyre inserts and unnecessary weight.
  • Precision Reinforced Carbon Layup – High-tensile fibers are strategically placed only where needed to create a strong, torsionally stiff structure while minimising overall weight.
  • CADEX Super Aero Carbon Spokes – High-tensile integrated carbon spokes with hidden nipples and independent internal tensioning minimise lateral flex for efficient acceleration and responsive climbing.
  • Dynamic Balanced Lacing (DBL) – A wider bracing angle and balanced spoke tension under pedalling load result in a stiffer wheel with outstanding power transfer and handling precision.
  • CADEX R3-C60 Aero Hub – An aerodynamic hub design with a 60-tooth ratchet delivers instant engagement for immediate power transfer over rough, technical terrain.
  • Ratchet Wave Spring System – A wave spring design ensures consistent, balanced ratchet engagement, resulting in smoother operation and improved rolling efficiency.
  • CADEX Hookless Rim Technology – An optimised carbon layup and hookless rim design reduce weight while improving durability and tyre stability under high-speed loads.
  • In-Mold Carbon Graphics – CADEX logos are integrated directly into the carbon surface for a clean, premium finish with no decals, no added weight, and no risk of fading.
Product Details

Specifications & Fit

  • Rim MaterialCarbon
    Rim TypeHookless
    TubelessCADEX Tubeless System (rim tape and valve kit included)
    Suggested Tyre Size700 x 40 -57c / 29 x 1.50–2.25"
    Rim Height50mm
    Rim Outer Width35mm
    Rim Inner Width25mm
    ETRTO622-25
    Front HubCADEX R3, Centerlock, One-piece integrated hub and spokes
    Rear HubCADEX R3-C60, Ratchet Driver, Centerlock, One-piece integrated hub and spokes
    Hub CompatibilitySRAM XDR / Shimano HG | MS / Campagnolo N3W
    BearingCADEX Ceramic Bearings
    Front Axle100x12 Thru Axle
    Rear Axle142x12 Thru Axle
    Spokes (Front)Super Aero carbon
    Lacing (Front)DBL, 16H
    Spokes (Rear)Super Aero carbon
    Lacing (Rear)DBL, 24H
    Nipple TypeIntegrated titanium
    WarrantyLifetime (registered original owner only)
    Incident Replacement5 years (registered original owner only)
    Weight without valves and tape (pair)1280g
    Weight with valves and tape (pair)1320g

    Specifications are subject to change without notice.
